EI30 2.5VA 230v ac 24v 24vac small isolation ac transformer

Designed and manufactured according regulations EN61558 EN61000 UL1446

Vacuum sealed

Safety transformer class II

Short-circuit-protected

Self-extinguishing plastic Isolation: Prim./Sec. = 10 MOhm to 500 Vcc - Sec./Sec. = 2 MOhm to 500 Vcc

Dielectric strength Prim. / Sec. = 4.5kV / 1min.

Full testing of all electrical parameters during production

Reliability tests for production batch (life term)

Certifications VDE, UL (E482368,E495460);
